OMNITRONIC CST-808 2-Way Ceiling Speaker

Frameless 2-way coaxial speaker, LF: 8" HF: 1", 8 ohms, 50 W RMS

Art. No.: 80710234

GTIN: 4026397709070

List price: 141.61 €

incl. 19% VAT.

Logistic

EAN / GTIN: 4026397709070

Weight: 3,14 kg

Length: 0.32 m

Width: 0.32 m

Heigth: 0.17 m

Description:

The models of the CST series are frameless in-ceiling speakers with a particularly discreet

appearance for installation in hotels, restaurants, bars, foyers, training and conference rooms or

shopping centers. The 2-way coaxial systems have a frequency response of up to 20 kHz,

balanced sound and excellent speech intelligibility. The tweeter is protected against overload by

a PTC and can be tilted 30 degrees to adapt to local conditions, as well as freely rotated by

360°. Secure mounting clamps allow for fast and easy attachment. The front grille is

exchangeable.

Features:

- Excellent sound playback

- With passive 2-way crossover, PTC tweeter protection

- Swivel tweeter

- Level matching switch -3 dB/0 dB/+3 dB

- For speech and background music in indoor PA systems

- Scratchproof and shockproof

Package contents

- 1 x speaker, 1 x user manual

Technical specications:

Power: Program: 100W

Rated: 50W RMS

Frequency range: 40 - 20000 Hz

Eurolite®, Futurelight®, PSSO®, Roadinger®, Alutruss®, Europalms® and Dimavery® are trademarks of Steinigke Showtechnic GmbH, Andreas-Bauer-Straße 5, DE-97297 Waldbüttelbrunn

Sensitivity: 88 dB

Max. SPL: 108 dB

Dispersion angle: 100° Omnidirectional

Impedance: 8 ohms

Speaker: 1 x woofer (8") approx. 20 cm

Tweeter (1") approx. 2.5 cm

Type of speaker: Flush-mount speaker

Material: ABS Acrylonitrile butadiene styrene

Color: White, scratchproof and shockproof

Mounting dimensions: 14,5 cm x Ø 24,6 cm

Dimensions: Depth: 14,2 cm

Diameter: Ø 28,5 cm

Weight: 2,50 kg
