SWIFT GROUP

Dunswell Road, Cottingham, East Yorkshire, HU16 4JX.

Tel: 01482 875740 Fax: 01482 840082

email: enquiry@swiftgroup.co.uk

website: www.swiftgroup.co.uk

A MEMBER OF THE SWIFT GROUP

Bolero / E500 Series

Specification, Wiring Diagrams & Bulb Chart

MotorhomesMotorhomes

1096229 Issued September 2011

iii 1

Contents

Standard Speciﬁcations ............................................................. 2

Optional Speciﬁcations .............................................................. 4

Capacities ................................................................................... 7

Towing Capabilities .................................................................... 8

Jacking ..................................................................................... 10

Wiring Diagrams ....................................................................... 11

Bulb Chart ................................................................................. 17

Bulb Replacement ...................................................................... 18

2 3

Standard Speciﬁcations

NOTE: 1. The Maximum User Payload includes:

a) the conventional load (this is the allowance for

passengers)

b) essential habitation equipment (items and

ﬂuids required for safe and proper functioning of

habitation equipment)

c) optional equipment (items available from

the manufacturer over and above the standard

speciﬁcation)

d) personal effects (those items not covered by

the above)

2. The Mass in Running Order is the mass of the

unladen vehicle including a 75kg allowance for the

driver plus engine coolants and 90% of the fuel tank,

water tank and gas capacity.

3. PLEASE TAKE CARE TO ENSURE THAT YOU HAVE

ALLOWED FOR THE MASSES OF ALL ITEMS YOU

INTEND TO CARRY IN THE MOTOR CARAVAN,

e.g. passengers, optional equipment, essential

habitation equipment and personal effects, such

as clothing, food, pets, bicycles, sailboards, sports

equipment etc.

4.WARNING - UNDER NO CIRCUMSTANCES

SHOULD THE MAXIMUM TECHNICAL PERMISSIBLE

LADEN MASS OF THIS MOTOR CARAVAN BE

EXCEEDED.

* For optional roof ladder (add 100mm).

Model Bolero 630PR / E520 Bolero 630EW / E540 Bolero 682FB / E562 Bolero 684FB / E564 Bolero 712SB / E572 Bolero 722FB / E582 Bolero 724FB / E584

Roof Proﬁle Low Proﬁle Low Proﬁle Low Proﬁle Low Proﬁle Low Proﬁle Low Proﬁle Low Proﬁle

Engine 130 MJT 130 MJT 130 MJT 130 MJT 150 MJT 150 MJT 150 MJT

Engine Capacity 2287cc 2287cc 2287cc 2287cc 2287cc 2287cc 2287cc

Engine Power 96kW @ 3600rpm 96kW @ 3600rpm 96kW @ 3600rpm 96kW @ 3600rpm 109kW @ 3600rpm 109kW @ 3600rpm 109kW @ 3600rpm

Torque 320Nm @ 1800rpm 320Nm @ 1800rpm 320Nm @ 1800rpm 320Nm @ 1800rpm 350Nm @ 1500rpm 350Nm @ 1500rpm 350Nm @ 1500rpm

Chassis

Fiat AL-KO low line Fiat AL-KO low line Fiat AL-KO low line Fiat AL-KO low line Fiat AL-KO low line Fiat AL-KO low line Fiat AL-KO low line

Wheel base 4.04m/13'3" 4.04m/13'3" 4.04m/13'3" 4.04m/13'3" 4.40m/14'5" 4.40m/14'5" 4.40m/14'5"

Designated Passenger Seats 1 1 1 3 1 1 3

Berths (sleeping positions) 2 2 4 4 4 4 4

Overall Length (no ladder)* 7.04m/23'1" 7.04m/23'1" 7.04m/23'1" 7.04m/23'1" 7.71m/25'3" 7.71m/25'3" 7.71m/25'3"

Overall Width (mirrors folded) 2.35m/7'9" 2.35m/7'9" 2.35m/7'9" 2.35m/7'9" 2.35m/7'9" 2.35m/7'9" 2.35m/7'9"

Overall Height 2.77m/9'1" 2.77m/9'1" 2.77m/9'1" 2.77m/9'1" 2.77m/9'1" 2.77m/9'1" 2.77m/9'1"

Maximum Technical Permissible

Laden Mass (A)

3500kg 3500kg 3500kg 3700kg 4250kg 4250kg 4250kg

Mass in Running Order (B)† 3190kg 3130kg 3125kg 3222kg 3335kg 3280kg 3345kg

Maximum User Payload (A-B) 310kg 370kg 375kg 478kg 915kg 970kg 905kg

Unladen Weight 2934kg 2874kg 2869kg 2966kg 3079kg 3024kg 3089kg

Essential Habitation Equipment 9kg 9kg 9kg 9kg 9kg 9kg 9kg

Thermal Insulation Grade THREE THREE THREE THREE THREE THREE THREE

Bed Sizes

Front Double 2.08m x 1.81m/1.33m / 6'10" x 5'11"/4'4" 2.08m x 1.23m/1.05m / 6'10" x 4'0"/3'5" 2.08m x 1.20m/1.05m / 6'10" x 3'11"/3'5" 2.08m x 1.23m/1.05m / 6'10" x 4'0"/3'5" 2.08m x 1.05m / 6'10" x 3'5"

2.08m x 1.20m/1.05m /

6'10" x 3'11"/3'5"

Front Nearside Single 1.93m x 0.71m / 6'4" x 2'4"

Front Offside Single 1.81m x 0.71m / 5'11" x 2'4"

Rear Double 2.08m x 1.78m / 6'10" x 5'10" 1.90m x 1.30m / 6'3" x 4'3" 1.90m x 1.30m / 6'3" x 4'3" 1.88m x 1.33m / 6'2" x 4'4" 1.88m x 1.33m / 6'2" x 4'4"

Rear Nearside Single 1.86m x 0.71m / 6'1" x 2'4" 1.89m x 0.71m / 6'2" x 2'4"

Rear Offside Single 1.78m x 0.71m / 5'10" x 2'4" 1.89m x 0.71m / 6'2" x 2'4"
