Oldal 1/16
SWIFT GROUP
Dunswell Road, Cottingham, East Yorkshire, HU16 4JX.
Tel: 01482 875740 Fax: 01482 840082
email: enquiry@swiftgroup.co.uk
website: www.swiftgroup.co.uk
A MEMBER OF THE SWIFT GROUP
1094802 issued July 2011
Challenger Sport
Eccles Sport
Specification, Wiring Diagrams & Bulb Chart
Touring CaravansTouring Caravans
1 2
Contents
Specification ..................................................................... 3
Wiring Diagrams - Road Lighting ..................................... 5
Wiring Diagrams - Roof Circuits ...................................... 6
Wiring Diagrams - Floor Circuits ...................................... 7
Wiring Diagrams - 230v Circuits ...................................... 8
Wiring Diagrams - Power Circuits .................................... 9
Wiring Diagrams - 13 pin Socket ................................... 10
Wiring Diagrams - Cable Colours .................................. 11
Bulb Chart ...................................................................... 12
Bulb Replacement .......................................................... 13
3 4
Specification
Challenger Sport 382 442 514 524 544 554 586 636
Eccles Sport 382 442 514 524 544 554 586 636
Berths 2 2 4 4 4 4 6 6
Axles 1 1 1 1 1 1 1 2
Internal Length (bed box height) 3.72m/12'2" 4.40m/14'5" 5.23m/17'2" 5.29m/17'4" 5.60m/18'4" 5.60m/18'4" 5.83m/19'2" 6.27m/20'7"
Overall Width 2.25m/7'5" 2.25m/7'5" 2.25m/7'5" 2.25m/7'5" 2.25m/7'5" 2.25m/7'5" 2.25m/7'5" 2.25m/7'5"
Overall Height (inc. TV Aerial)* 2.64m/8'8" 2.64m/8'8" 2.65m/8'8" 2.65m/8'8" 2.65m/8'8" 2.65m/8'8" 2.65m/8'8" 2.62m/8'7"
Maximum Internal Headroom 1.95m/6'5" 1.95m/6'5" 1.95m/6'5" 1.95m/6'5" 1.95m/6'5" 1.95m/6'5" 1.95m/6'5" 1.95m/6'5"
Overall Length 5.37m/17'7" 6.06m/19'11" 6.88m/22'7" 6.94m/22'9" 7.25m/23'9" 7.25m/23'9" 7.48m/24'6" 7.93m/26'0"
Awning A/A dimension† 8.11m/26'7" 8.79m/28'10" 9.62m/31'7" 9.68m/31'9" 9.99m/32'9" 9.99m/32'9" 10.22m/33'6" 10.66m/35'0"
Mass in Running Order (inc. tolerance) 1028kg/20.2cwt 1114kg/21.9cwt 1230kg/24.2cwt 1255kg/24.7cwt 1282kg/25.2cwt 1277kg/25.1cwt 1371kg/27.0cwt 1470kg/28.9cwt
Maximum Technical Permissible Laden
Mass (Lower limit)
1143kg/22.5cwt 1235kg/24.3cwt 1380kg/27.2cwt 1405kg/27.7cwt 1435kg/28.2cwt 1430kg/28.1cwt 1547kg/30.5cwt 1650kg/32.5cwt
Maximum Technical Permissible Laden
Mass (Upper limit)
1200kg/23.6cwt 1350kg/26.6cwt 1500kg/29.5cwt 1500kg/29.5cwt 1500kg/29.5cwt 1500kg/29.5cwt 1600kg/31.5cwt 1800kg/35.4cwt
Total user Payload 115kg/2.3cwt 121kg/2.4cwt 150kg/3.0cwt 150kg/3.0cwt 153kg/3.0cwt 153kg/3.0cwt 176kg/3.5cwt 180kg/3.5cwt
Personal Effects 115kg/2.3cwt 121kg/2.4cwt 150kg/3.0cwt 150kg/3.0cwt 153kg/3.0cwt 153kg/3.0cwt 176kg/3.5cwt 180kg/3.5cwt
Options 0kg/0cwt 0kg/0cwt 0kg/0cwt 0kg/0cwt 0kg/0cwt 0kg/0cwt 0kg/0cwt 0kg/0cwt
Tyre Size 175 R14C 99Q 175 R14C 99Q 185 R14C 102Q 185 R14C 102Q 185 R14C 102Q 185 R14C 102Q 195/70 R15C 104R 175/65 R14 86T
Tyre pressure at Lower limit MTPLM 3.5 bar / 51 psi 3.9 bar / 57 psi 4.0 bar / 58 psi 4.0 bar / 58 psi 4.1 bar / 59 psi 4.1 bar / 59 psi 4.2 bar / 61 psi 2.4 bar / 35 psi
Tyre pressure at Upper limit MTPLM 3.7 bar / 54 psi 4.3 bar / 62 psi 4.4 bar / 64 psi 4.4 bar / 64 psi 4.4 bar / 64 psi 4.4 bar / 64 psi 4.4 bar / 64 psi 2.7 bar / 39 psi
Static Load on Coupling Head 100kg 100kg 100kg 100kg 100kg 100kg 100kg 100kg
Thermal Insulation Grade THREE THREE THREE THREE THREE THREE THREE THREE
Bed Sizes
Front Double
208cm x 180cm/6'10" x 5'11" 208cm x 180cm/6'10" x 5'11" 208cm x 159cm/6'10" x 5'3" 208cm x 180cm/6'10" x 5'11" 208cm x 159cm/6'10" x 5'3" 208cm x 159cm/6'10" x 5'3" 208cm x 180cm/6'10" x 5'11" 208cm x 180cm/6'10" x 5'11"
or Front Nearside Single
190cm x 72cm/6'3" x 2'4" 190cm x 72cm/6'3" x 2'4" 180cm x 72cm/5'11" x 2'4" 190cm x 72cm/6'3" x 2'4" 180cm x 72cm/5'11" x 2'4"
and Front Offside Single
180cm x 72cm/5'11" x 2'4" 180cm x 72cm/5'11" x 2'4" 190cm x 72cm/6'3" x 2'4" 180cm x 72m/5'11" x 2'4" 190cm x 72cm/6'3" x 2'4"
Rear Double
196cm x 131cm/6'5" x 4'4" 194cm x 132cm/6'4" x 4'4" 189cm x 133cm/6'2" x 4'4"
Rear Bunk
Side Single (offside)
180cm x 62cm/5'11" x 2'0"
Side Single (nearside)
180cm x 67cm/5'11" x 2'2" 180cm x 92cm/5'11" x 3'0"
Side Bunk (offside)
176cm x 59cm/5'9" x 1'11"
Side Bunk (nearside)
176cm x 59cm/5'9" x 1'11"
Rear Fixed Lower Bunk
Rear Fixed Mid Bunk
Rear Fixed Upper Bunk
Side Fixed Lower Bunk
182cm x 57cm/6'0" x 1'10" 183cm x 56cm/6'0" x 1'10"
Side Fixed Mid Bunk
183cm x 57cm/6'0" x 1'10"
Side Fixed Upper Bunk
182cm x 57cm/6'0" x 1'10" 183cm x 56cm/6'0" x 1'10"
Weights: From the 2011 season the method of
calculating the Mass in Running Order (MRO) and
user payload figures has changed in order to bring it
in line with European Vehicle Directives.
Allowances for essential equipment (e.g. gas
cylinders) previously allowed for in the user payload
are now contained within the MRO. A provision for a
leisure battery which used to be within the essential
equipment payload has now been included within the
personal effects payload allowance.
Although the method of calculation has changed, the
overall effect is that the amount of payload available
to the customer has remained the same, it is just
calculated in a different manner
Bed Sizes : Please note that the front double bed
sizes quoted are for seating configurations without
chest of drawers. The front double bed width for a
layout with a chest of drawers fitted will be reduced
by 0.4m(1'4") from that stated.
Awning sizes: Due to varying awning designs and
sizes the awning sizes given are approximate only.
Specific awning sizes must be confirmed by your
dealer or awning manufacturer prior to purchase.
* The dimensions given are approximate due to slight
variations in suspension ride heights, loading
conditions and tyre pressures.
Customers should verify the actual dimensions of
their touring caravan before committing to anything
that could be impacted by theses dimensions
Please note: Any dealer fit options will reduce the
overall payload available to the user of the caravan.
If you require additional payload it is possible to
upgrade the MTPLM to the upper limit. Pleas contact
your Swift caravan dealer for more information.
