Oldal 1/20
Swift Group
Dunswell Road
Cottingham
East Yorkshire HU16 4JX
Tel 01482 847332
Fax 01482 841042
email enquiry@swiftgroup.co.uk
For more information visit
www. .co.ukswiftgroup
Issued July 2013
1404401
Challenger SE - Conqueror
Eccles SE - Elite
Technical Handbook
1
Contents
Challenger SE Specifications 2 .....................................................
Eccles SE Specifications 4 ............................................................
Conqueror - Elite Specifications ................................................. 6
Wiring Diagrams 8 .........................................................................
Bulb Chart 15 .................................................................................
Bulb Replacement 16 ......................................................................
3
2
Specification
Challenger Challenger 480 Challenger 530 Challenger 565 Challenger 570 Challenger 580 Challenger 590 Challenger 620 Challenger 625 Challenger 630 Challenger 645
Berths 2 4 4 4 4 6 4 6 6 4
Axles 1 1 1 1 1 2 2 2 2 2
Internal Length (bed box height) 4.40m/14'5" 5.29m/17'4" 5.60m/18'4" 5.60m/18'4" 5.83m/19'2" 6.27m/20'7" 6.27m/20'7" 6.27m/20'7" 6.27m/20'7" 6.27m/20'7"
Overall Width* 2.25m/7'4½" 2.25m/7'4½" 2.25m/7'4½" 2.25m/7'4½" 2.25m/7'4½" 2.25m/7'4½" 2.25m/7'4½" 2.25m/7'4½" 2.25m/7'4½" 2.25m/7'4½"
Overall Height (inc. TV Aerial)* 2.64m/8'8" 2.65m/8'8" 2.65m/8'8" 2.65m/8'8" 2.65m/8'8" 2.62m/8'7" 2.62m/8'7" 2.62m/8'7" 2.62m/8'7" 2.62m/8'7"
Maximum Internal Headroom 1.95m/6'5" 1.95m/6'5" 1.95m/6'5" 1.95m/6'5" 1.95m/6'5" 1.95m/6'5" 1.95m/6'5" 1.95m/6'5" 1.95m/6'5" 1.95m/6'5"
Overall Length* 6.06m/19'11" 6.94m/22'9" 7.25m/23'9" 7.25m/23'9" 7.48m/24'6" 7.93m/26'0" 7.93m/26'0" 7.93m/26'0" 7.93m/26'0" 7.93m/26'0"
Awning A/A dimension 8.77m/28'9" 9.65m/31'8" 9.96m/32'8" 9.96m/32'8" 10.19m/33'5" 10.64m/34'11" 10.64m/34'11" 10.64m/34'11" 10.64m/34'11" 10.64m/34'11"
Mass in Running Order (inc. tolerance) 1166kg/23.0cwt 1331kg/26.2cwt 1360kg/26.8cwt 1330kg/26.2cwt 1360kg/26.8cwt 1615kg/31.8cwt 1579kg/31.1cwt 1603kg/31.6cwt 1564kg/30.8cwt 1575kg/31.0cwt
Maximum Technical Permissible Laden
Mass (Lower limit)
1287kg/25.3cwt 1481kg/29.2cwt 1513kg/29.8cwt 1483kg/29.2cwt 1516kg/29.8cwt 1850kg/36.4cwt 1800kg/35.4cwt 1800kg/35.4cwt 1800kg/35.4cwt 1800kg/35.4cwt
Maximum Technical Permissible Laden
Mass (Upper limit)
1350kg/26.6cwt 1500kg/29.5cwt 1550kg/30.5cwt 1500kg/29.5cwt 1550kg/30.5cwt 1850kg/36.4cwt 1800kg/35.4cwt 1800kg/35.4cwt 1800kg/35.4cwt 1800kg/35.4cwt
Total user Payload 121kg/2.4cwt 150kg/3.0cwt 153kg/3.0cwt 153kg/3.0cwt 156kg/3.1cwt 235kg/4.6cwt 221kg/4.4cwt 197kg/3.9cwt 236kg/4.6cwt 225kg/4.4cwt
Personal Effects 121kg/2.4cwt 150kg/3.0cwt 153kg/3.0cwt 153kg/3.0cwt 156kg/3.1cwt 180kg/3.5cwt 160kg/3.1cwt 180kg/3.5cwt 180kg/3.5cwt 160kg/3.1cwt
Options 0kg/0cwt 0kg/0cwt 0kg/0cwt 0kg/0cwt 0kg/0cwt 0kg/0cwt 0kg/0cwt 0kg/0cwt 0kg/0cwt 0kg/0cwt
Tyre Size 185 R14C 102Q 185 R14C 102Q 185 R14C 102Q 185 R14C 102Q 185 R14C 102Q 185/70 R14 88T 185/70 R14 88T 185/70 R14 88T 185/70 R14 88T 185/70 R14 88T
Tyre pressure at Lower limit MTPLM 52 psi / 3.6bar 62 psi / 4.3bar 64 psi / 4.4bar 62 psi / 4.3bar 64 psi / 4.4bar 33 psi / 2.3bar 32 psi / 2.2bar 32 psi / 2.2bar 32 psi / 2.2bar 32 psi/2.2bar
Tyre pressure at Upper limit MTPLM 55 psi / 3.8bar 64 psi / 4.4bar 65 psi / 4.5bar 64 psi / 4.4bar 65 psi / 4.5bar 33 psi / 2.3bar 32 psi / 2.2bar 32 psi / 2.2bar 32 psi / 2.2bar 32 psi / 2.2bar
Static Load on Coupling Head 100kg 100kg 100kg 100kg 100kg 100kg 100kg 100kg 100kg 100kg
Thermal Insulation Grade THREE THREE THREE THREE THREE THREE THREE THREE THREE THREE
Bed Sizes
Front Double
202cm x 176cm/6'8" x 5'9" 202cm x 176cm/6'8" x 5'9" 202cm x 156cm/6'8" x 5'1" 202cm x 156cm/6'8" x 5'1"
202cm x 156cm
/6'8" x 5'1"
202cm x 176cm
/6'8" x 5'9"
202cm x 176cm
/6'8" x 5'9"
202cm x 176cm
/6'8" x 5'9"
203cm x 131cm
/6'8" x 4'4"
202cm x 156cm
/6'8" x 5'1"
or Front Nearside Single
186cm x 72cm/6'1" x 2'4" 176cm x 72cm/5'9" x 2'4" 156cm x 72cm/5'1" x 2'4" 156cm x 72cm/5'1" x 2'4" 156cm x 72cm/5'1" x 2'4" 186cm x 72cm/6'1" x 2'4" 176cm x 72cm/5'9" x 2'4" 176cm x 72cm/5'9" x 2'4" 156cm x 72cm/5'1" x 2'4"
and Front Offside Single
176cm x 72cm/5'9" x 2'4" 186cm x 72cm/6'1" x 2'4" 156cm x 72cm/5'1" x 2'4" 156cm x 72cm/5'1" x 2'4" 156cm x 72cm/5'1" x 2'4" 176cm x 72cm/5'9" x 2'4" 186cm x 72cm/6'1" x 2'4" 186cm x 72cm/6'1" x 2'4" 156cm x 72cm/5'1" x 2'4"
Rear Double
192cm x 130cm/6'4" x 4'3"
185cm x 133cm
/6'1" x 4'4"
202cm x 133cm
/6'8" x 4'4"
192cm x 130cm
/6'4" x 4'3"
192cm x 130cm
/6'4" x 4'3"
185cm x 133cm
/6'1" x 4'4"
Side Single (offside)
180cm x 62cm/5'11" x 2'0" 192cm x 68cm/6'4" x 2'3" 186cm x 64cm/6'1" x 2'1" 192cm x 68cm/6'4" x 2'3"
180cm x 69cm
/5'11" x 2'3"
180cm x 62cm
/5'11" x 2'0"
Side Single (nearside)
183cm x 73cm/6'0" x 2'5" 176cm x 64cm/5'9" x 2'1" 183cm x 73cm/6'0" x 2'5"
Side Bunk (offside)
176cm x 59cm/5'9" x 1'11"
173cm x 59cm
/5'8" x 1'11"
176cm x 59cm
/5'9" x 1'11"
176cm x 59cm
/5'9" x 1'11"
Side Bunk (nearside)
163cm x 59cm
/5'4" x 1'11"
Side Fixed Lower Bunk
Side Fixed Mid Bunk
Side Fixed Upper Bunk
Weights: From the 2011 season the method of
calculating the Mass in Running Order (MRO) and
user payload figures has changed in order to bring it
in line with European Vehicle Directives.
Allowances for essential equipment (e.g. gas
cylinders) previously allowed for in the user payload
are now contained within the MRO. A provision for a
leisure battery which used to be within the essential
equipment payload has now been included within the
personal effects payload allowance.
Although the method of calculation has changed, the
overall effect is that the amount of payload available
to the customer has remained the same, it is just
calculated in a different manner
Bed Sizes : Please note that the front double bed
sizes quoted are for seating configurations without
chest of drawers. The front double bed width for a
layout with a chest of drawers fitted will be reduced
by 0.4m(1'4") from that stated.
Awning sizes: Due to varying awning designs and
sizes the awning sizes given are approximate only.
Specific awning sizes must be confirmed by your
dealer or awning manufacturer prior to purchase.
* The dimensions given are approximate due to slight
variations in suspension ride heights, loading
conditions and tyre pressures.
Customers should verify the actual dimensions of
their touring caravan before committing to anything
that could be impacted by theses dimensions
Please note: Any dealer fit options will reduce the
overall payload available to the user of the caravan.
If you require additional payload it is possible to
upgrade the MTPLM to the upper limit. Pleas contact
your Swift caravan dealer for more information.
** Estimated
