Oldal 1/20
Swift Group
Dunswell Road
Cottingham
East Yorkshire HU16 4JX
Tel 01482 847332
Fax 01482 841042
email enquiry@swiftgroup.co.uk
For more information visit
www. .co.ukswiftgroup
Issued July 2013
1404354
Challenger Sport -
Eccles Sport
Technical Handbook
1
Contents
Challenger Sport Specifications 2 .................................................
Eccles Sport Specifications 4 .......................................................
Wiring Diagrams 6 .........................................................................
Bulb Chart 13 .................................................................................
Bulb Replacement 14 ......................................................................
3
2
Specification
Challenger Sport 442 514 524 544 554 564 584 586 636 640
Berths
2 4 4 4 4 4 4 6 6 6
Axles
1 1 1 1 1 1 1 1 2 2
Internal Length (bed box height)
4.40m/14'5" 5.23m/17'2" 5.29m/17'4" 5.60m/18'4" 5.60m/18'4" 5.60m/18'4" 5.83m/19'2" 5.83m/19'2" 6.27m/20'7" 6.27m/20'7"
Overall Width*
2.25m/7'4½" 2.25m/7'4½" 2.25m/7'4½" 2.25m/7'4½" 2.25m/7'4½" 2.25m/7'4½" 2.25m/7'4½" 2.25m/7'4½" 2.25m/7'4½" 2.25m/7'4½"
Overall Height (inc. TV Aerial)*
2.64m/8'8" 2.65m/8'8" 2.65m/8'8" 2.65m/8'8" 2.65m/8'8" 2.65m/8'8" 2.65m/8'8" 2.65m/8'8" 2.62m/8'7" 2.62m/8'7"
Maximum Internal Headroom
1.95m/6'5" 1.95m/6'5" 1.95m/6'5" 1.95m/6'5" 1.95m/6'5" 1.95m/6'5" 1.95m/6'5" 1.95m/6'5" 1.95m/6'5" 1.95m/6'5"
Overall Length*
6.06m/19'11" 6.88m/22'7" 6.94m/22'9" 7.25m/23'9" 7.25m/23'9" 7.25m/23'9" 7.48m/24'6" 7.48m/24'6" 7.93m/26'0" 7.93m/26'0"
Awning A/A dimension
8.79m/28'10" 9.62m/31'7" 9.68m/31'9" 9.99m/32'9" 9.99m/32'9" 9.99m/32'9" 10.22m/33'6" 10.22m/33'6" 10.66m/35'0" 10.66m/35'0"
Mass in Running Order (inc. tolerance)
1118kg/22.0cwt 1234kg/24.3cwt 1258kg/24.8cwt 1292kg/25.4cwt
†
1279kg/25.2cwt
†
1290kg/25.4cwt 1295kg/25.5cwt 1361kg/26.8cwt 1508kg/29.7cwt 1542kg/30.4cwt
Maximum Technical Permissible Laden
Mass (Lower limit)
1239kg/24.4cwt 1384kg/27.2cwt 1408kg/27.7cwt 1445kg/28.4cwt
†
1432kg/28.2cwt 1443kg/28.4cwt 1451kg/28.6cwt 1550kg/30.5cwt 1750kg/34.4cwt 1750kg/34.4cwt
Maximum Technical Permissible Laden
Mass (Upper limit)
1350kg/26.6cwt 1500kg/29.5cwt 1500kg/29.5cwt 1500kg/29.5cwt 1500kg/29.5cwt 1500kg/29.5cwt 1500kg/29.5cwt 1550kg/30.5cwt 1800kg/35.4cwt 1850kg/36.4cwt
Total user Payload
121kg/2.4cwt 150kg/3.0cwt 150kg/3.0cwt 153kg/3.0cwt 153kg/3.0cwt 153kg/3.0cwt 156kg/3.1cwt 189kg/3.7cwt 242kg/4.8cwt 208kg/4.1cwt
Personal Effects
121kg/2.4cwt 150kg/3.0cwt 150kg/3.0cwt 153kg/3.0cwt 153kg/3.0cwt 153kg/3.0cwt 156kg/3.1cwt 176kg/3.5cwt 180kg/3.5cwt 180kg/3.5cwt
Options
0kg/0cwt 0kg/0cwt 0kg/0cwt 0kg/0cwt 0kg/0cwt 0kg/0cwt 0kg/0cwt 0kg/0cwt 0kg/0cwt 0kg/0cwt
Tyre Size
185 R14C 102Q 185 R14C 102Q 185 R14C 102Q 185 R14C 102Q 185 R14C 102Q 185 R14C 102Q 185 R14C 102Q 185 R14C 102Q 185/70 R14 88T 185/70 R14 88T
Tyre pressure at Lower limit MTPLM
3.5 bar / 51 psi 4.0 bar / 58 psi 4.1 bar / 59 psi 4.2 bar / 61 psi 4.1 bar / 59 psi 4.2 bar / 61 psi 4.2 bar / 61 psi 4.5 bar / 65 psi 2.1 bar / 30 psi 2.1 bar / 30 psi
Tyre pressure at Upper limit MTPLM
3.8 bar / 55 psi 4.4 bar / 64 psi 4.4 bar / 64 psi 4.4 bar / 64 psi 4.4 bar / 64 psi 4.4 bar / 64 psi 4.4 bar / 64 psi 4.5 bar / 65 psi 2.2 bar / 32 psi 2.3 bar / 33 psi
Static Load on Coupling Head
100kg 100kg 100kg 100kg 100kg 100kg 100kg 100kg 100kg 100kg
Thermal Insulation Grade
THREE THREE THREE THREE THREE THREE THREE THREE THREE THREE
Bed Sizes
Front Double
202cm x 180cm
6'8" x 5'11"
202cm x 153cm/
6'8" x 5'0"
202cm x 180cm/
6'8" x 5'11"
202cm x 159cm/
6'8" x 5'3"
202cm x 159cm/
6'8" x 5'3"
202cm x 159cm/
6'8" x 5'3"
202cm x 159cm/
6'8" x 5'3"
202cm x 180cm/
6'8" x 5'11"
202cm x 180cm/
6'8" x 5'11"
202cm x 180cm/
6'8" x 5'11"
or Front Nearside Single
190cm x 72cm/6'3" x 2'4" 153cm x 72cm/5'0" x 2'4" 180cm x 72cm/5'11" x 2'4" 160cm x 72cm/5'3" x 2'4" 160cm x 72cm/5'3" x 2'4" 160cm x 72cm/5'3" x 2'4" 160cm x 72cm/5'3" x 2'4" 190cm x 72cm/6'3" x 2'4" 180cm x 72cm/5'11" x 2'4" 190cm x 72cm/6'3" x 2'4"
and Front Offside Single
180cm x 72cm/5'11" x 2'4" 160cm x 72cm/5'3" x 2'4" 190cm x 72cm/6'3" x 2'4" 160cm x 72cm/5'3" x 2'4" 160cm x 72cm/5'3" x 2'4" 160cm x 72cm/5'3" x 2'4" 160cm x 72cm/5'3" x 2'4" 180cm x 72cm/5'11" x 2'4" 190cm x 72cm/6'3" x 2'4" 180cm x 72cm/5'11" x 2'4"
Rear Double
198cm x 133cm/6'6" x 4'4" 191cm x 133cm/6'3" x 4'4" 191cm x 133cm/6'3" x 4'4" 185cm x 133cm/6'1" x 4'4" 202cm x 133cm/6'8" x 4'4"
Rear Bunk
Side Single (offside)
180cm x 62cm/5'11" x 2'0" 192cm x 71cm/6'4" x 2'4" 186cm x 64cm/6'1" x 2'1"
Side Single (nearside)
183cm x 75cm/6'0" x 2'6" 180cm x 62cm/5'11" x 2'0" 180cm x 82cm/5'11" x 2'8" 176cm x 64cm/5'9" x 2'1"
Side Bunk (offside)
176cm x 59cm/5'9" x 1'11" 173cm x 59cm/5'8" x 1'11"
Side Bunk (nearside)
176cm x 59cm/5'9" x 1'11" 176cm x 59cm/5'9" x 1'11" 163cm x 59cm/5'4" x 1'11"
Rear Fixed Lower Bunk
Rear Fixed Mid Bunk
Rear Fixed Upper Bunk
Side Fixed Lower Bunk
183cm x 57cm/6'0" x 1'10" 181cm x 57cm/5'11" x 1'10"
Side Fixed Mid Bunk
Side Fixed Upper Bunk
183cm x 57cm/6'0" x 1'10" 181cm x 57cm/5'11" x 1'10"
Weights: The method of calculating the Mass in
Running Order (MRO) and user payload figures has
changed in order to bring it in line with European
Vehicle Directives.
Allowances for essential equipment (e.g. gas
cylinders) previously allowed for in the user payload
are now contained within the MRO. A provision for a
leisure battery which used to be within the essential
equipment payload has now been included within the
personal effects payload allowance.
Although the method of calculation has changed, the
overall effect is that the amount of payload available
to the customer has remained the same, it is just
calculated in a different manner
Bed Sizes : Please note that the front double bed
sizes quoted are for seating configurations without
chest of drawers. The front double bed width for a
layout with a chest of drawers fitted will be reduced
by 0.4m(1'4") from that stated.
Awning sizes: Due to varying awning designs and
sizes the awning sizes given are approximate only.
Specific awning sizes must be confirmed by your
dealer or awning manufacturer prior to purchase.
* The dimensions given are approximate due to slight
variations in suspension ride heights, loading
conditions and tyre pressures.
Customers should verify the actual dimensions of
their touring caravan before committing to anything
that could be impacted by theses dimensions
Please note: Any dealer fit options will reduce the
overall payload available to the user of the caravan.
If you require additional payload it is possible to
upgrade the MTPLM to the upper limit. Pleas contact
your Swift caravan dealer for more information.
