BEFORE INFLATING YOUR AIRSPRING FORK, CHECK AND DO NOT EXCEED FACTORY RECOMMENDED PRESSURES.

CONNECTING TO AIRSPRING FORK

PRESSURE-RITE SHOCK ADAPTER

User's Guide

WARNINGWARRANTY

GB

CONNECTING TO REAR SHOCK

Waeressure rkly then inflting shock or tub, the peading will rise quico the pe inside the shock ressur

or tube will need o be inceased ue. Pressurtrntil the check e inside the valvPressure-Ritevice de is

opened. You will notie a sligt decease in pchrressurvalvs. Wccurs, e when the check e openhen this o

your gauge will indicate the correct pressure reading. Pump to desired pressure.

Aftrarer desied infltion pessueacherre is d, dist pump head fom the connecrPressure-Ritece dvie first

before disting the e de fom the shock or tubour pump has a pconnecPressure-Ritevicre. If yressure

rtcvatto release buton, atie it elease pressure beforccrPrre-Rite e disonneting pump head fom the essu

device.

Do not leave Pressure-Rite connected if it's not being used to inflate.

1.

2.

3.

Inflating...

Inflating...

Copyright © Topeak, Inc. 2014 M-TSA-01-GB 10/14

2-year Warranty: All mechanical components against manufacturing defects only.

Warranty Claim Requirements

To obtain warranty service, you must have your original sales receipt. Items

returned without a sales receipt will assume that the warranty begins on the

date of manufacture. All warranties will be void if the product is damaged due

to user crash, abuse, system alteration, modification, or used in any way not

intended as described in this manual.

* The specifications and design are subject to change without notice.

Please contact your Topeak dealer with any questions.

For USA customer service call: 1-800-250-3068

www.topeak.com

CONNECTING TO PUMP HEAD ON 12" or 14" WHEEL

Lock

Unlock

Due to larger volume, using a floor

pump with Pressure- Rite Shock

Adapter will quickly inflate a fork or

shock air-spring. In order to prevent

over inflation and possible damage

to the air chamber, we strongly

recommend using a floor pump with

this shock adapter to 20 psi / 2 bar

below your target pressure and

inflate to the final pressure using a

standard mini shock pump.

Make sure the air release valve

is fully closed before installing

Pressure-Rite on Schrader valve

of fork or shock.

Thread Pressure-Rite onto

Schrader valve.

Carefully inflate airspring fork or

shock to desired pressure. Use

Air Release Knob to fine tune air

pressure.

After fine tuning air pressure,

close Air Release Knob

completely.

Remove Pressure-Rite from from

Schrader valve.

1.

2.

3.

4.

5.

INFLATION NOTES:

BEFORE INFLATING YOUR REAR SHOCK, CHECK AND DO NOT EXCEED FACTORY RECOMMENDED PRESSURES.

2

1

2

1

1

2

2

3

1

1

2

3

3

Air release knob allows

fine tuning air pressure.

Air release knob allows

fine tuning air pressure.

Lock

1

2

Lock

Unlock

Unlock
