INSTALLATION INSTRUCTIONS

99-7382HG

Metra. The World’s Best Kits.

®

MetraOnline.com © COPYRIGHT 2024 METRA ELECTRONICS CORPORATION REV. 3/20/24 INST99-7382HG

ATTENTION: With the key out of the ignition,

disconnect the negative battery terminal before

installing this product. Ensure that all installation

connections, especially the air bag indicator lights, are

plugged in before reconnecting the battery or cycling

the ignition to test this product.

NOTE: Refer also to the instructions included with the

aftermarket accessory before installing this device.

KIT FEATURES

• ISO DIN radio provision with pocket

• ISO DDIN radio provision

• Includes SWC, antenna adapter, and wiring harness

• Retains the factory backup camera

• Includes a climate display to retain the information that was

displayed on the factory radio

• Includes a built-in hazard switch

• Painted high gloss black

KIT COMPONENTS

• A) Radio trim panel with climate display and hazard switch • B) Radio brackets • C) Pocket • D) (4) #8 x 3/8” Phillips screws

• Not Shown: Wiring harness, Antenna adapter

TOOLS REQUIRED

• Panel removal tool

• Phillips screwdriver

• 5/16” Socket wrench

• Wire cutter • Crimp tool

• Solder gun • Tape

• Connectors (example:

butt-connectors, bell caps, etc.)

TABLE OF CONTENTS

Dash Disassembly ..................................................2

Kit Assembly

–ISO DIN radio provision with pocket ..................3

–ISO DDIN radio provision ....................................3

Wiring Instructions ...........................................4-12

Final Assembly .......................................................7

WIRING & ANTENNA CONNECTIONS

Wiring Harness: Included with kit

Antenna Adapter: Included with kit

Steering Wheel Control Interface: Included with kit

12V-to-6V Camera Step-Down: Included with kit

AB

D

C

Kia Niro (without NAV) 2017-2019

Visit MetraOnline.com for more detailed information about the product and up-to-date vehicle

specific applications
