AX-AB-LX1

INSTALLATION INSTRUCTIONS

AxxessInterfaces.com © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 7/16/20 INSTAX-AB-LX1

Attention!Let the vehicle sit with the key

out of the ignition for a few minutes before

removing the factory radio. When testing the

aftermarket equipment, ensure that all factory

equipment is connected before cycling the

key to ignition.

TOOLS REQUIRED

• Crimping tool and connectors, or solder gun,

solder, and heat shrink

• Tape • Wire cutter • Zip ties

TABLE OF CONTENTS

Amplifier locations ................................................2

Connections

-Lexus .....................................................................3

-Subaru ...............................................................3-4

-Toyota ................................................................4-7

Lexus/Subaru/Toyota Amplifier Bypass Harness

2012-Up

Refer to the following pages for the vehicle specific instructions for

wiring connections. Wiring connections vary per vehicle.

If it’s uncertain whether the vehicle contains a specific speaker or not,

test the wires with a tone generator, or check to see if the factory

wires are populated on the vehicle side. Alternatively, the wires can

be tested for impedance with a multimeter.

APPLICATIONS

Lexus

CT200H 2014-2017

ES300H 2013-2018

ES350 2013-2018

GS F 2016-Up

GS200T 2015-2017

GS300 2018-Up

GS350 2015-Up

GS450H 2013-Up

GX460

(9-spk. system) 2013-Up

IS350 (w/ NAV) 2013-Up

IS250 (w/ NAV) 2013-2015

IS F (w/ NAV) 2013-2014

IS200T 2016-2017

IS250C (w/ NAV) 2013-2015

IS300 2016-Up

IS350C (w/ NAV) 2013-2015

NX200T 2015-2017

NX300H 2015-2017

RC F 2015-2017

RC200T 2016-2017

RC300 2016-2017

RC350 2015-2017

RX350 2013-2017

RX450H 2013-Up

Subaru

Ascent 2019-Up

Crosstrek 2018-Up

Forester 2019-Up

Impreza 2017-Up

Legacy 2015-Up

Outback 2015-Up

Toyota

Avalon 2013-Up

Camry 2012-Up

Mirai 2016-Up

Highlander 2014-Up

Land Cruiser 2013-Up

Prius 2012-Up

RAV4 2013-Up

Visit AxxessInterfaces.com for more detailed information about the product and up-to-date

vehicle specific applications
