AXLOC-NIS

I N S TA L L A T I O N I N S T R U C T I O N S

ATTENTION: With the key out of the ignition,

disconnect the negative battery terminal

before installing this product. Ensure that all

installation connections, especially the air

bag indicator lights, are plugged in before

reconnecting the battery or cycling the

ignition to test this product.

NOTE: Refer also to the instructions included

with the aftermarket accessory before

installing this device.

TOOLS REQUIRED

• Crimping tool and connectors, or solder gun,

solder, and heat shrink

• Tape • Wire cutter • Zip-ties

TABLE OF CONTENTS

Applications.............................................................1

Installation ............................................................. 2

Diagram .................................................................. 3

APPLICATIONS

Visit AxxessInterfaces.com for more detailed information about the product and up-to-date vehicle speciﬁc applications.

• Designed to provide (2) channels of low-level audio output from the factory system.

• Allows for the installation of an ampliﬁer for speakers or subwoofers.

• Gain Controller included to adjust the overall output.

• 12v-500mA remote wire activated with signal sense.

• 55-watts per channel.

• Designed for non-ampliﬁed vehicles.

Note: A single pole double throw (SPDT) relay is recommended when installing multiple ampliﬁers.

KIT COMPONENTS

• AXLOC-NIS Wiring Harness

• Gain Controller

• 12v-500mA Remote Wire

• Auxiliary Cable

For dash disassembly instructions, refer to . Enter the year, make, and model of the vehicle in the for .metraonline.com Vehicle Fit Guide Radio Install Kits

Nissan LOC (Line Output Converter)

AXLOC-NIS

(for Non-Ampliﬁed Vehicles)

1995-2013

Inﬁniti

FX35, FX45 2003-2008

G20 1995-1996

Nissan

200SX 1995-1998

240SX 1995-1998

350Z 2003-2009

Altima 1995-2006
