FIREPLACE TV MOUNT
MI-395
MI-395WHT
Scan this QR code for
product information, videos,
and assembly assistance.

Thank you for choosing Mount-It
2
COMPATIBLE VESA SIZES
COMPATIBLE WITH
TVs UP TO
Mount-It!
Mount-It!

Attach the Spring Arm (B) and Wall Plate (A) with bolts (4 x I) as shown, using the Allen Wrench (Q) to
tighten securely.
4
Installing The Spring Arm To The Wallplate
Placing Washer (J) on the 3 exposed bolts on the Spring Arm (B) attach TV BRACKET (C) as shown
then secure with Washer (K) and Nut (L). Use Wrench (T) to tighten securely.
Installing The TV Bracket To The Spring Arm
Install Plastic Plate (H) to cover the nuts from the previous step inserting Bolt (M) from the opposite side
as shown using a screwdriver to tighten.
Attaching The Plastic Plate To The TV Bracket
Step 1
Step 2
