Warning

Bridge Connector

CAMFM25-B-- G4

Brief descriptionFestoCoKG SE & .

Postfach

73726sslingen E

Deutschland

+4

9 711 347-0

www.festo.com

Translation:en

Purpose of the bridge connector

Bridge connectors servetobypass emergencystop contactors,forthe

reason a handheld terminal.to operatemachine a without

Safety notes

Warning

Danger of personal injurydueto electricshock!

−Use theconnectorexclusivelyfrom systems a thathave

protectivevoltage low (e.g.SELV orPELV accordingtoEN

611312:2007).-

Warning

−To avoid accidentscausedbyincorrectorabusiveusage(e.g.

usagebridge - onnondesignateddevices),the connectormust

onlybe byor connected safetypersonnel people,whoare

familiar with the risks.

−Pay alsoattention to the subchapter "Application of Emergency

Stop Button and StopButton onthe Handheld Terminal" of the

chapter " Appendix: MachinerySafety" in theuser manual of

the handheld terminal.

Warning

In case of incorrect installation or use,dangeroussituationsmayarise.

−This productinsertmustbekeptthroughouttheentireservice

life of the product.

−The installation andapplication ofthe product maybe

performed onlybyqualifiedpersonnel.

−When using bridge connectors, no E-stopfunction is given by the

handheld terminal. Therefor an additional E-stop must be present

on the machine.

−In case safety functionsonly are neutralisedforpartsofthe

system/machine, otherprotective equipmenthaveto bearranged

for theseparts.

−In case of disconnectable emergencystopdevices(e.g.wearable

programmingmeasures devices),appropriate haveto beplanned

to avoid the confusionbetween effectualeffectual -andnon control

devices.

−An assessmentof riskmustbearranged(whichrisksarisewhen

using bridge connectors)andif necessarythecontructionof the

machineand organizational arrangementsmustbe adapted.

Caution

−Machines can take damage ifcaseofunpluggingthebridge

connector - duringoperation,becauseofthemissinghotplug

compatibility stationof theremote theunpluggingaffectsasan

E-Stop.

Pin assignment

Mat.Nr.NameProducerPinsPin-bridges

55567617 -B-- CAMFM25G4Hummel 3-5-6 4

8153040

2021-04

[8153042]
